buildings and basements. It will have co-exis-
tence withmobile broadband services, thereby
facilitating new M2M business model innova-
tion and the ability to play a key connectivity
role in the various solutions that make up IoT
solutions.
The LE910 is essentially two high-speed cel-
lular modules in one. An LTE 3GPP Category
3 module delivering data rates of 100Mbps
downlink and 50Mbps uplink and an HSPA
+ module delivering up to 42Mbps downlink
and 5.76Mbps uplink rates. It falls back auto-
matically to HSPA + if it is unable to register
onto an LTE network. Two different series
of variants are available, one for the North
American market and another for the Euro-
pean. Both include multiband configurations,
covering different sets of 4G and 3G bands
as well as MNO certifications. The LE910
also includes multiple-input multiple-output
(MIMO) technology, an essential feature to
meet demands for data rate and link reliability.
The LE910 V2 is an LTE 3GPP Category 4
module delivering data rates of 150Mbps
downlink and 50Mbps uplink. It’s ideal for
regions with high 4G penetration levels. Multi
network support for North America and
Europe is provided.
The LE920 Auto Series combines two high-
speed cellular modes: TE delivering 100Mbps
downlink and 50Mbps uplink data rates
and full fallback compatibility with HSPA
+. LE920 modules are also fully backward
compatible with existing GSM/GPRS net-
works, which enables connectivity in remote
areas where there is no 3G coverage. The
series comprises band-combination vari-
ants designed for the market requirements in
North America. The series was developed and
manufactured according to ISO TS16949 pro-
cesses, making it ideal for automotive OEMs.
The M.2 family data cards deliver LTE high-
speed data rates for PC OEM device manufac-
turers. The M.2 form factor is ideal for devices
having very high throughput requirements
such as PDAs, e-readers, tablets, and mobile
computing or consumer electronics. The fam-
ily enables a natural transition from the Mini
Card PCI and Half Mini Card to a smaller
form factor. Features include lower power
consumption, high-speed USB interfaces and
support for multiple operating systems.
The LN930 M.2 achieves download rates to
150Mbps through support of 3GPP release 9.
There are two variants; both support the var-
ious RF frequency bands and band combina-
tions that are deployed worldwide. The LN930
LTE for North America and Europe plus
roaming in Asia Pacific. The LN930-AP LTE
APAC is especially developed for Asia Pacific.
The LN932 M.2 achieves download rates to
300Mbps through support of 3GPP release
10 LTE Carrier Aggregation. There are two
variants. The LN932 M.2 LTE Advanced sup-
ports the various RF frequency bands and
band combinations that are deployed world-
wide. The LN932 LTE Advanced is suited for
North America and Europe plus roaming in
Asia Pacific.
Despite the enormous potential of the market
for smart cars, only 8% of the cars in the world
are actually connected to the Internet. Never-
theless, all the top 14 automotive
manufacturers, which account for 80% of the
market, have a connected-car strategy. This
indicates that their strategy is long-term.
The requisite hardware platforms are being
embedded today in order to launch applica-
tions tomorrow, and then at a later date the
manufacturer can decide how they need to
grow or change.
ATOP platform combines formidable pro-
cessing power in order to support almost all
conceivable telematics applications with LTE
4G cellular for voice and data communication.
Therefore it enables the creation of future-
proof solutions, both from an application/ser-
vice perspective as well as connectivity since
it removes any uncertainty about future 2G or
3G sunsets.
n
The LE910 V2 is an LTE 3GPP Category 4 module delivering data rates of 150 Mbps downlink
and 50 Mbps uplink .
The LE920 Series combines two high speed cellular modes: LTE and full fallback capability with
HSPA+.
The ATOP platform supports LTE 4G cellular
for voice and data communication
